high end cabin with large window door

Redefine Boundaries

Take the Indoor & Outdoor Lifestyle to the Next Level With the Ultimate Sliding Glass Wall System

The Liftslide

Sizes
  • Custom and standard sizes available
  • Panels built as tall as 16’ with AAMA ratings
  • Rough openings as wide as 60’, panels up to 1300 lbs.
  • Coastal ratings tested for oversized panels to TAS (Miami-Dade protocol)and ASTM standards
  • Configuration
  • Panels slide straight, curved, corner, into a wall pocket, jamb to jamb, barn door style, or custom options
  • Aluminum profile is an extruded 6063 alloy
  • The 3-3/16˝ profile design accepts either a ½” aluminum or ½” wood cladding attached to the interior by a patented fastening system that joins them structurally while separating them physically and thermally
  • Same sash design used for Liftslides, pivot doors, swing doors, Beefy Bifolds, and large fixed units
  • Performance
  • Patented flush track with only 3/16˝ profile above the finished floor
  • AAMA tested for air, water, and wind loads
  • Hardened anodized aluminum track that has been time tested for over 25 years in harsh weather environments.
  • Impact ratings available for various materials including the aluminum wood liftslide
  • Coastal rated pocketing Liftslide doors tested with wall pockets and high-performance flush drainage track
  • Materials
  • Three material designs: various materials including aluminum with wood interior cladding and all wood
  • Tracks extruded from corrosion-resistant marine-grade aluminum and anodized
  • Standard woods are mahogany, Doug fir, poplar, pine, and alder
  • Any wood available for upcharge
  • Screens
  • Designed and integrated into the door system
  • Standard screen is aluminum, 1-3/8˝ thick, max 8’ x 11’ panel size
  • Other screen sash options:
  • - All wood: 1-3/4”, 2-1/4”. 2-5/8”, 3-3/16” thickness options
    - Oversized screens use Liftside sash profiles

    Hardware
  • Permanent handles (standard on jamb to jamb systems)
  • Removable handles (standard on pocketing systems)
  • Rocky Mountain flush handles by request
  • GU/Ferco architectural hardware is standard
  • Finish
  • Virtually any color matched
  • High quality AAMA 2605 finish
  • Kynar 500 is standard finish with outstanding color retention and weather resistance
  • Powder coating and anodized finishes are also available
  • FDL Bars
  • 1-1/4”, 1”, 7/8” widths
  • colors: bronze, champagne, mill, black
  • 7/8” and 1-1/4” contemporary or colonial, available in aluminum or wood
  • 2-7/8” lock rail (true divided lite), available in all wood, aluminum wood, and all-aluminum
  • Standard FDL includes shadow bars or grids between glass on IG units
  • Glass
  • Overall glass makeup is available up to 1-9/16˝ thick can be ordered to match most other glass on a project or meet necessary energy requirements
  • SmartSun™ and other available coatings greatly reduce heat transfer and UV rays
  • Simulated divided light (SDL/FDL) and true divided lite options
  • Triple glazing available
  • Easier Installation
  • Weiland tracks are pre-assembled for easier and more accurate installation
  • A built-in marker assists in accurately installing the finished floor at only 3/16˝ below the top of the track
  • All units are installed in the Weiland plant before shipping to your job site to ensure perfect fit and operation
  • Windows and Doors of the Highest Quality and Value
